Adjustable Braid Thermocouples

Adjustable Braid Thermocouple Standard Specifications

  • 3/16″ diameter probe
  • Fits standard bayonet adapters
  • 12″ spring with bayonet cap
  • Grounded construction
  • 24 ga. fiberglass leads with stainless steel armor
  • Spade lugs

Metric Sizes Also Available

  • 12 mm cap with 4.75 mm diameter probe

  • 14 mm cap with 8 mm diameter probe

Options

  • 2 wire or 3 wire RTD
  • Custom probe length
  • Polarized plug or jack
  • 20 ga. lead wire
  • Additional lead lengths available
  • Custom orders welcome

Termination Options

  • Stripped Leads
  • Spade Lugs
  • Mini Plug
  • Mini Jack
  • Standard Plug
  • Standard Jack

Type Options

  • Type J
  • Type K
  • Type T
  • RTD
  • Grounded
  • Ungrounded

Description

Adjustable Depth Thermocouples w/ Stainless Steel Overbraid

Type J with Spade Lugs
Stock Number
JBS24-G1-24R1
JBS36-G1-24R1
JBS48-G1-24R1
JBS72-G1-24R1
JBS96-G1-24R1
JBS120-G1-24R1
JBS144-G1-24R1
Type J with Polarized Plug
Stock Number
JBS24-G1-24R2
JBS36-G1-24R2
JBS48-G1-24R2
JBS72-G1-24R2
JBS96-G1-24R2
JBS120-G1-24R2
JBS144-G1-24R2


Lead Length
24”
36”
48”
72”
96”
120”
144”

Type K with Spade Lugs
Stock Number
KBS24-G1-24R1
KBS36-G1-24R1
KBS48-G1-24R1
KBS72-G1-24R1
KBS96-G1-24R1
KBS120-G1-24R1
KBS144-G1-24R1
Type K with Polarized Plug
Stock Number
KBS24-G1-24R2
KBS36-G1-24R2
KBS48-G1-24R2
KBS72-G1-24R2
KBS96-G1-24R2
KBS120-G1-24R2
KBS144-G1-24R2


Lead Length
24”
36”
48”
72”
96”
120”
144”

Type J Ungrounded with Spade Lugs

Stock Number
JBS24-U1-24R1
JBS36-U1-24R1
JBS48-U1-24R1
JBS72-U1-24R1
JBS96-U1-24R1
JBS120-U1-24R1
JBS144-U1-24R1
Lead Length
24”
36”
48”
72”
96”
120”
144”
