Cable Clamps and Grommets
PART NUMBER
BH40 Cable Clamp
BH40-3 Cable Clamp for 3/8″ element or 1/4″ Armor Sheath
BH44 Neoprene Clamp Grommet
Stacks Image 39Stacks Image 41

Neoprene Wire Entrance Grommets
Nylon Wire Protection Washers

PART NUMBERS
Grommets BH41
Washers BH42
Stacks Image 50

Crimping Inserts

PART NUMBERS

BH89-0 Undrilled
BH89-020 020″ Tube
BH89-040 040″ Tube
BH89-1 1/16″ Tube
BH89-2 1/8″ Tube
BH89-3 3/16″ Tube
BH89-4 (same as BH84) 1/4″ Tube
BH89-3MM 3mmTube
BH89-4.5MM 4.5 mm Tube
BH89-6 MM 6 mm Tube

Stacks Image 59

Stainless Steel L-Bracket Brazing Adaptors
PART NUMBERS
BH99-2 = 2 Hole Mount, Undrilled
BH99-2-2 = 2 Hole Mount, .129″ Braze Hole
BH99-3 = 3 Hole Mount, Undrilled
BH99-3-4 = 3 Hole Mount, 1/4″ Braze Hole
BH99-3-6 = 3 Hole Mount, 3/8″ Braze Hole
BH99-3-7 = 3 Hole Mount, 7/16″ Braze Hole
Stacks Image 68Stacks Image 70

Tube Adaptors

PART NUMBERS

BH5040 = .040″ Tube
BH51 = 1/16″ Tube
BH52 = 1/8″ Tube
BH53 = 3/16″ Tube
BH54 = 1/4″ Tube
BH55 = 5/16″ Tube
BH56 = 3/8″ Tube

Note:
Tube Adaptor has Brass Ferrules
1/8” Stainless Ferrules
P/N# BHP1622-SS
1/8” Nylon Ferrules
P/N# BHP1622-NY
1/8” OD x 1/16” ID
Split Brass Sleeve – BH59

Stacks Image 79


Adaptor Inserts

PART NUMBERS

BH7040 = .040″ Tube
BH71 = 1/16″ Tube
BH72 = 1/8″ Tube

Stacks Image 90

Note:
Brass Compression Type Tubing Adaptors held by Slots Within the Standard Case and 3-Pin Cases.


Brazing Inserts

PART NUMBERS

BH80 = Undrilled
BH8020 = .020″ Tube
BH8040 = .040″ Tube
BH81 = 1/16″ Tube
BH82 = 1/8″ Tube
BH83 = 3/16″ Tube
BH84 = 1/4″ Tube (same as H89-4)
BH84-6MM = 6mm Tube

Stacks Image 101

Stainless Steel Spool-Type Brazing Inserts

PART NUMBERS

BH90 = Undrilled
BH91 = 1/16″ Tube
BH92 = 1/8″ Tube
BH93 = 3/16″ Tube
BH94 = 1/4″ Tube
BH95 = 5/16″ Tube
BH96 = 3/8″ Tube

Stacks Image 110


Dual Cable Clamps

PART NUMBER

BH60

Stacks Image 119

Assemble Standard Connectors into Dual Connectors

Accommodate either One or Two Lead-In Cable


Dual Tube Adaptors

PART NUMBERS

BH61 = 1/16″ Tube
BH62 = 1/8″ Tube
BH63 = 3/16″ Tube
BH64 = 1/4″ Tube
BH65 = 5/16″ Tube
BH66 = 3/8″ Tube

Stacks Image 130

Assemble Standard Connectors into Dual Connectors


Filler Plate Set

PART NUMBER

BH69

Stacks Image 141

When Combined with Dual Tube Adaptor or Dual Cable Clamp, the Filler Plate Set provides the 3/4″ pin spacing of a single unit Duplex Connector


Neoprene Boots

PART NUMBER

BH420

Stacks Image 152

When Combined with Dual Tube Adaptor or Dual Cable Clamp, the Filler Plate Set provides the 3/4″ pin spacing of a single unit Duplex Connector
