Accessories for High Heat Thermocouple Connectors

Specifications

• Glass Filled Thermoset Bodies (Reddish-Brown Color)
• Temperature Rating of 800° F Continuous or 1000° F. Intermittent
• Hollow Pins in Plugs Standard. Solid Pins Available on Request
• Jack is Spring Loaded with High Temp Spring
• Polarity and Calibration Marked
• Knurled Finger Grips

Description

Available Plugs and Jacks

ANSI Calibration = Case Color

Type J = Black

Type K = Yellow

Type T = Blue

Type R/S = Green

Type E = Purple

Type N = Orange

Type U = White

Cable Clamps

For Ultra-High Temp Connectors

PART NUMBER
BHTR40

Crimping/Brazing Inserts

For Ultra-High Temp Connectors

PART NUMBERS
BHTR89-040….. .040″ Tube
BHTR89-1………. 1/16″ Tube
BHTR89-2………. 1/8″ Tube
BHTR89-3……… 3/16″ Tube
BHTR89-4……… 1/4″ Tube

Dual Tube Adaptors

For Ultra-High Temp Connectors
Assemble Ultra-Hight Temp Connectors in Dual Connectors

PART NUMBERS

BHTR61………….1/16″ Tube
BHTR62………….1/8″ Tube
BHTR63………….3/16″ Tube
BHTR64………….1/4″ Tube

Tube Adaptors

For Ultra-High Temp Connectors

PART NUMBERS

BHTR51………….1/16″ Tube
BHTR52………….1/8″ Tube
BHTR53………….3/16″ Tube
BHTR54………….1/4″ Tube
BHTR55………….5/16″ Tube
BHTR56………….3/8″ Tube

Calibration

J
K
T
R (S)
U
E
N

Common Name

Iron/Constantan
Chromel/Alumel
Copper/Constantan
Platinum/Rhodium
Copper/Copper (uncompensated)
Chromel/Constantan
Nicrosil/Nisil

Case Color

Black
Yellow
Blue
Green
White
Purple
Orange
